OUT OF STOCK - PLEASE ALLOW 2 WEEKS PLUS DELIVERY SERVICE
NEED SOMETHING SOONER? SEE BELOW FOR ALTERNATIVE PRODUCTS
|
|
The HECO-TOPIX-plus Part Thread Countersunk Screws are structural timber screws manufactured from hardened carbon steel with a bright zinc-plated A3K finish. Their partial-thread design pulls timber components firmly together, while the countersunk head finishes flush with the timber surface.
Designed for professional timber construction, these screws are suitable for timber-to-timber connections, internal joinery, staircase construction and general carpentry. The zinc-plated finish is intended primarily for dry internal or protected applications; select a suitable stainless steel or corrosion-resistant fixing where greater environmental exposure is expected.
HECO-TOPIX-plus part thread countersunk screws are designed to produce secure timber-to-timber connections. The unthreaded section allows the upper component to be drawn tightly against the supporting timber as the screw is driven.
Key features:
These structural wood screws are intended for timber-to-timber connections where a strong clamping action and flush countersunk finish are required.
Typical applications include:
Technical note: The required screw diameter, length, quantity, spacing, edge distance and embedment must be established from the manufacturer’s guidance and the project-specific structural design. Pre-drilling may be required in hardwood, dense timber or where reduced edge distances are used.
Technical note: Always use the latest manufacturer documentation and project-specific design when determining the required fixing specification.
Specifics
Nominal diameter: 8mm
Overall length: 260mm
Thread length: 100mm
Thread type: Partial thread
Head type: Countersunk head with milling grooves
Head diameter: 14.8mm
Drive recess: HECO-Drive HD-40 (T40 compatible)
Box quantity: 50
Selling unit: Each
Material: Carbon steel
Surface finish: Bright zinc plated, A3K
Approval reference: ETA-19/0553
Manufacturer part number: 61349
Previous manufacturer part number: 48102
EAN: 4019787613491
Installation: Use the drive recess specified for the selected screw and keep the driver aligned with the screw axis. Drive the head flush with the timber without over-tightening. Pre-drilling is not normally required in suitable softwood within the approved conditions, but may be necessary in hardwood, dense materials or close to timber edges. Structural connections must follow the applicable ETA, manufacturer guidance and project design.
